Local RAG Stack with ChromaDB & Ollama: Air-Gapped Setup (2026)

Quick Answer: To build a production-grade, 100% private local RAG (Retrieval-Augmented Generation) pipeline, combine Ollama for model inference, ChromaDB for on-disk vector storage, and BAAI/bge-m3 for dense multilingual embeddings. This setup runs entirely air-gapped on local consumer hardware without transmitting corporate data to external APIs.

Last Updated: September 8, 2026 | Reviewed by Senior Systems Architect

Key Takeaways

• 100% Data Sovereignty: Zero external API calls; all vector indexing, embedding generation, and prompt completion occur on localhost.
• Embedding Selection: BGE-M3 provides state-of-the-art 8,192 token context retrieval, outperforming legacy OpenAI text-embedding-ada-002 on technical documentation.
• Vector Storage: ChromaDB operates in-process with SQLite persistence, requiring zero server daemon management.
• Hardware Footprint: The entire stack (DeepSeek R1 14B + BGE-M3 + ChromaDB) consumes only 12.2 GB VRAM, fitting within an RTX 3080 or RTX 4070 GPU.

---

1. Local RAG Architecture & Component Stack

Layer	Component	Memory Footprint	Role
Inference Engine	Ollama (DeepSeek R1 14B)	9.6 GB VRAM	Context Synthesis & Reasoning
Embedding Model	BAAI/bge-m3	2.2 GB VRAM	Dense Multi-vector Indexing
Vector Database	ChromaDB (v0.6+)	~400 MB RAM	Local Inverted Index & Cosine Distance
Document Parser	Docling / PyPDF	~250 MB RAM	Chunking & Table Reconstruction

---

2. Setting Up the Local Embedding & Inference Endpoints

First, pull the embedding model and the reasoning generation model using Ollama:

# Pull multi-lingual embedding model
ollama pull bge-m3

# Pull local reasoning model
ollama pull deepseek-r1:14b

Review our DeepSeek R1 Local Setup Guide for parameter optimizations like setting temperature to 0.6 to preserve chain-of-thought accuracy.

---

3. Minimal Python RAG Pipeline Implementation

Install the lightweight client libraries:

pip install chromadb ollama langchain-community

Create local_rag.py:

import chromadb
from chromadb.utils import embedding_functions
import ollama

# 1. Initialize persistent local ChromaDB
client = chromadb.PersistentClient(path="./local_knowledge_db")
collection = client.get_or_create_collection(name="internal_engineering_docs")

# 2. Ingest document chunk
collection.add(
    documents=["RTX 4090 power limit is 450W with 24GB GDDR6X VRAM."],
    ids=["doc_001"]
)

# 3. Query relevant context
query = "What is the power consumption and memory of RTX 4090?"
results = collection.query(query_texts=[query], n_results=1)
retrieved_context = results['documents'][0][0]

# 4. Generate local synthesis with Ollama
response = ollama.chat(
    model='deepseek-r1:14b',
    messages=[
        {'role': 'system', 'content': f'Context: {retrieved_context}'},
        {'role': 'user', 'content': query}
    ]
)
print(response['message']['content'])

For scaling to multiple concurrent queries across local development teams, review our Ollama vs vLLM Concurrency Benchmark. Refer to the Official ChromaDB Documentation for HNSW index configurations.

---

Frequently Asked Questions

Can ChromaDB run completely without an internet connection?

Yes, once the Python wheels and Ollama model weights are downloaded, ChromaDB operates locally with zero outbound network requests.

How does BGE-M3 compare to OpenAI text-embedding-3-small?

In empirical MTEB benchmarks, BGE-M3 achieves a higher NDCG@10 score on code retrieval (72.4 vs 69.8) and supports native 8,192 token chunking.
